Round Bottle Labeling Machine

Round Bottle Labeling Machine
Round Bottle Labeling Machine
Product Code : 18
Product Description

Approx. Price: Rs 15,000 / piece.

Note: Price is only for display purpose. Prices will depends upon dimensions and machines size type.

In line with clients' diverse requirements across the country, we are offering a commendable range of Round Bottle Labeling Machine. For strictly adhering to international industry guidelines, we manufacture the provided machine employing quality-proven components and supreme technology in conformation with current market norms. Our offered machine is used diverse industries for labeling the bottles. Our in-house quality checking unit enable us to deliver defect-free machine at our patron's end.

Operation: The round containers positioned & curate spacing between two containers by the belt spacing device and a belt drive mechanism hold the container from top of the container for two sides labeling on flat container at the labeling point, an electronics product sensor sense container & relies a label from self adhesive label roll. If machine is equipped with batch printing device in that case batch printing device prints the batch no. & other matter on label during label is stationary means time between sensing of two label. The sensed round container moves on conveyor sticker label at labeling point wrapped around to container. Then the labeled container moves further through a rubber pressing belt & stationary rubber pad that ensures neat & perfect fixing of label.

Technical Information:
  • Food Grade (SS 304) Slat Chain Flat Conveyor for stickering on Round Bottles
  • AC Drives: 0.5 HP for Conveyor & 0.5 HP for Bottle orientation
  • Conveyor Length of Machines should be 5– 6 feet.
  • Containers Placing on Slat Chain Conveyor through Round Turn Table or Manual (OPTIONAL)
  • Bottle & Label Scanner Sensor with Container Hold stoppers for Accurate labeling on Bottles
  • Machine Frame Structure Covering Steel Covering Food Grade S.S. 304
  • Programming Logical Controlled (PLC) system (Make: PANASONIC, SIEMENS, OMRON)
  • Digitally Touch Screen Display for Machine Parameter Setting (Make: PANASONIC, SIEMENS, OMRON)
  • Product Sensor to sense the gap between labels
  • AC Variable Frequency Drives controlled conveyor and belt speed (Make: ALLEN BRADLEY, SIEMENS)
  • Power: 0.25 HP Conveyor Motor & Pressing Device Motor
  • Break Assembly to avoid variation during releasing of the sticker rolls.
  • Anti Vibration pad will be provided to avoid vibration during operation of the machine.
  • Electrical Load: 1.2 KW with Single /Three Phase Connected Load
  • Sticker Roll Stepper Motor: 6 V DC
  • SERVO motor controller for sticker releasing (Make: PANASONIC, SIEMENS, OMRON)
Specifications:
  • Filling range up to 2000 ml
  • Sticker Size: up to 200 mm
  • Labeling Material: Self Adhesive Sticker Roll form
  • No Bottle No Sticker mechanism inbuilt.
  • Speed: up to 3000 per hour (depend on the stickers and sizes)
Other Details:
  • Item Code: KI-R-BOTTLE-LABEL
  • Pay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer), Other
  • Minimum Order Quantity: 1 piece
  • Port of Dispatch: ICD, PPG (DELHI), TKD (DELHI), JNPT (MUMBAI)
  • Production Capacity: 1000 PIECES PER YEAR
  • Packaging Details: STRONG WOODEN PACKING WITH STRETCH WRAPPING
